SKU#:
0936170
Part No:
ES8100
Features
- Unlocks under a Pre-Load of up to 100kg in 3-wire mode, 15kg in 2-wire mode
- Locks under a Pre-Load of 20kg (12W) and 35kg (24W)
- 1000kg Holding Force
- IP53 rated for external door applications
- Door Position and Lock Status Monitoring
- On-Board visual Lock Status indication and diagnostics LED
About this product
Additional features
- Easy, one-step, Fail Safe (PTL) and Fail Secure (PTO) field selection
- Optional Surface / Glass mount Kit
- May be mounted vertically or horizontally (must not be mounted in the floor)
- Allows for door misalignment of up to 12mm total (+/-6mm)
- Operating voltage: 11.4 - 26VDC
- Durability tested to 500,000 cycles (120N unlocking, 50N locking)
More Information
| Stock |
In Stock |
| Part Number |
ES8100 |
| Brand |
Trimec |
| Category |
Access, Locks |
