Slim single lock-monitored ECO friendly magnetic lock. Its compact design makes it ideal for most indoor applications where 275kg holding force is sufficient. Monitoring provides LED lock status indication and relay contacts for signalling.
FEATURES
HALF THE POWER CONSUMPTION ALL THE HOLDING FORCE
Voltage input: 12VDC-24VDC
Compatible with existing maglock and associated bracket range
MOV provides spike and surge protection
Fail-safe operation (power to lock)
Anti-residual magnetism protection
Top-plate, armature-plate and fixings included
Slim design, Surface mount
Silver anodised aluminium finish
Lock monitoring
Hall bond sensor & LED monitor door status
TECHNICAL INFORMATION
Holding force: up to 275kg (600lbs)
Low consumption energy
Current draw = 250mA @ 12VDC / 130mA @ 24VDC
Voltage tolerance: +/- 5%
Operating temp: -10°C to +55°C
Zero residual: Mechanical (Kick off button)
Weight: 2.5kg approx.
Relay: COM/NO/NC
