This is the Grade 3 Shock Sensor, complete with a Magnetic Contact and is the perfect replacement for the now obsolete ‘Honeywell Viper’ range of shock sensors.
Grade 3
Black ABS housings
Combined Shock / Tilt Sensor and Magnetic Contact unit
Complies with the brand new EN50131-2-8:2016 standard and therefore PD6662:2017 to Grade 3
Sensitivity Auto calibration
Sensitivity pot
Selectable EOL and Alarm resistors
Rear tamper detection (meeting Grade 3)
LED enable jumper
Suitable for mounting in the ‘V BOX’
Pulse count selectable on board
Pulse count selectable via serial link
Vibration and surface / tilt detection selectable on board
Motion sensing available on any movement along the vertical plane
Vibration and surface / tilt detection selectable via serial link
Fault output
Selectable Fault resistors
Latch terminal
First to Alarm memory
Remote LED enable
Heartbeat LED
Serial connection option
EOL Resistor options
1k,2k2,4k1,4k7,5k6
Alarm Resistor options
1k,2k2,4k1,4k7,5k6,6k8
Fault Resistor options
2k2,3k,6k8,12k
Dimensions(mm)
88 x 25 x 22.8
