Knight 4 Terminal Flush Resister – Brown
SKU#:
0904590
Part No:
A51MULTIB
Order on Request
Order on Request
About this product
BROWN – Not white like shown in image
The A51MULTIB is a 4 terminal brown flush contact complete with selectable EOL/Alarm resistors. It will fit a standard 20mm diameter recess, expanding to 22mm if the optional contact sheath is used. The round plate is 24mm in diameter.
EOL Resistors: 1k, 2k2, 4k1, 4k7, 5k6, 10k.
Alm Resistors: 1k, 2k2, 4k1, 4k7, 5k6, 6k8, 10k.
These resistors cover the majority of leading panel manufacturers including Honeywell, Texecom, HKC, Risco etc.
Tamper protection is provided by a spring loaded microswitch. This will detect removal from the fitted recess.
The contact can be wired without the integral resistors (Traditional / 4-Wire) if necessary.
Fitting tacks are provided with this contact for immediate installation from the package.
A51MULTIB is suitable for shared zone installation with 2+ contacts.
- Operating gap: ~14mm
- Microswitch tamper protection
- Integral resistors (module selection)
- Shared zone ready
- Fits standard 20mm diameter recess (22mm with sheath)
- Round plate
| Stock | Order on Request |
|---|---|
| Detector Type | Flush Contact |
| Wired Or Wireless | Wired |
| Grade | Grade 2 |
| Part Number | A51MULTIB |
| Brand | Knight |
| Category | Intruder, Intruder Detectors |
